Single Sign-On (SSO) in Salesforce

Step 4: Configure the Remote Site Settings in Salesforce (Service Provider)

      1.Navigate to Remote Site Settings:

• Go to Setup in Salesforce.
• In the Quick Find box, type Remote Site Settings and select it.

     2. Create a New Remote Site:
     Click on the New Remote Site

• Enter the Details:
• Remote Site Name: Enter a descriptive name for the Identity Provider (e.g., “IdP_Remote_Site”).
• Remote Site URL: Enter the domain URL of the Identity Provider (IdP) (e.g., https://idp.example.com).
• Optionally, provide a description for better clarity.

     3. Save the Configuration:

Click Save to add the new Remote Site.

Step 5. Configure Single Sign-On Settings in Salesforce (SP)

1. Navigate to Setup→ Quick Find → Single Sign-On Settings -> SAML Enabled

2. Configure SAML Settings in Salesforce (SP)

Navigate to Setup→ Quick Find → Single Sign-On Settings -> New

 The user can configure the Single Sign-On using the New button by

Provide the following details:

• Name: Descriptive name (e.g., “Okta SSO”).
• SAML Version: Select 2.0.
• Issuer: Enter the Issuer URL provided by your IdP.
• Entity ID**: Use your Salesforce Org’s Entity ID (pre-filled in Salesforce).
• Identity Provider Login URL: Enter the IdP login URL.
• Identity Provider Certificate: Upload the certificate file from the IdP.
• Assertion Consumer Service (ACS) URL: Ensure this pre-filled field matches your Salesforce instance.
• Service Provider Initiated Request Binding: Select HTTP POST.
• SAML Identity Location: Use Identity is in the Name Identifier element of the Subject statement.
• Subject Type: Use User ID or Federated ID as appropriate.
• Save your configuration.

Configuring Single Sign-On (SSO) Using a New Metadata File

1. Download the Metadata File:

• Access the Identity Provider (IdP) configuration interface.
• Download the metadata file (typically an XML file) provided by the IdP.

1. Navigate to SAML Single Sign-On Settings in Salesforce:

• Go to Setup in Salesforce.
• In the Quick Find box, type Single Sign-On Settings and select it.

1. Create a New SAML Single Sign-On Setting:

• Click on New to create a new SSO configuration.
• Select SAML as the SSO type.

1. Upload the Metadata File:

• Locate the option to Upload Metadata File.
• Click Choose File and upload the metadata file downloaded from the IdP.

1. Verify and Save:

• Salesforce will automatically populate the required SAML configuration fields (e.g., Entity ID, Assertion Consumer Service URL) based on the metadata file.
• Verify the details to ensure correctness.
• Click Save to complete the setup.

The user can configure Single Sign-On by using the Metadata URL from the Identity Provider (IdP) organization.

1. Navigate to the Identity Provider Settings in Salesforce:

• Go to Setup in Salesforce.
• In the Quick Find box, type Identity Provider and select Salesforce Identity from the results.

2. Copy the Metadata URL:

• Locate the Identity Provider Metadata section.
• Copy the provided Metadata URL.

3. Paste the Metadata URL in the Service Provider (SP) Settings:

• Go to the Service Provider (SP) settings in your Salesforce org.
• Paste the copied Metadata URL into the relevant field labeled Metadata URL.
• Click on Create.

4. Automatic Data Population:

• Once you click Create, Salesforce will automatically populate the SSO settings using the information from the Metadata URL.
• The populated details will be displayed on the screen for verification.

1. Update the Identity Provider Certificate:

• Download the required certificate file from the Identity Provider (IdP) organization.
• In Salesforce:
• Navigate to Setup→ Quick Find→ Identity Provider.
• Locate the section for uploading a certificate.
• Upload the downloaded certificate file and save the changes.

2. Select the Correct Identity Mapping:

• In the SAML Single Sign-On Settings:
• Specify how Salesforce should map users between the Identity Provider and Service Provider.
• Options for identity mapping include:
• Username: Match users based on their Salesforce username.
• -User ID: Match users based on their unique Salesforce user ID.
• Federation ID: Match users based on their federation ID.
• In this case, select Federation ID as the identity mapping method.

3. Save and Verify the Configuration:

• Once all required fields are populated and the configuration is complete:
• Click Save.
• This will create the SAML Single Sign-On Settings record in Salesforce.

Review the settings to ensure that everything is configured correctly.

Step 6: Create a Connected App in the Identity Provider (IdP) Org

1. Navigate to App Manager:

• Go to Setup in the IdP organization.
• In the Quick Find box, type App Manager and select it.

• Fill in the following required fields:
• Connected App Name: Enter a descriptive name for your app (e.g., “SSO_SAML_ConnectedApp”).
• API Name: This will be auto-filled based on the app name.
• Contact Email: Provide a valid email address for the app administrator.
  • Enable SAML Settings:
• Check the Enable SAML box to configure SAML-based authentication for the app.

Configure SAML-Specific Settings:

• Enter the required fields under the SAML settings section:
• Entity ID: Enter a unique identifier for the app (often matches the Service Provider’s Entity ID).

Navigate to Setup→ Quick Find → single sign on settings (SP Org) à Entity Id

Enter the ACS URL which we will get from SP org single sign on setting data

Navigate to Setup→ Quick Find → single sign on settings à Login Url

Idp certificate select the new created self-signed certificate

Step 7 : Enter the Federation id on the both the user record on IDP and SP org

Navigate to Setup→ User setting → Advance user details à Edit -> Federation Id
